HomeSiren Jeweller

Jeweller communication technology

Proprietary wireless communication technology to transmit commands, alarms, and events.

Key features:

• Two-way communication.
• Advanced anti-sabotage.
• Block encryption featuring a dynamic key.
• Instant notifications.
• Remote control and configuration in Ajax apps.

Frequency bands

866.0–866.5 MHz
868.0–868.6 MHz
868.7–869.2 MHz
905.0–926.5 MHz*
915.85–926.5 MHz
921.0–922.0 MHz

Depends on the sales region.

* Certified according to UL/ULC standards.

Maximum effective radiated power (ERP)

up to 25 mW

Automatic power control to reduce power consumption and radio interference.

Radio signal modulation

GFSK

Radio communication range

up to 6,500 ft

Between the device and a hub (or a range extender) in an open space.

Encrypted communication

All stored and transmitted data are protected by block encryption featuring a dynamic key.

Frequency hopping

To prevent radio interference and jamming.

Battery

2 × CR123A

Pre-installed.

Calculated battery life

up to 5 years

Siren’s operating voltage range

1.9−3.3 V⎓

Siren’s nominal operating voltage

3 V⎓

Quiescent siren’s current consumption at nominal voltage

68 µA

Peak siren’s current consumption at nominal voltage

1.1 A

When the siren sounds at the Very Loud volume level.

Average siren’s current consumption at nominal voltage

50 mA

When the siren sounds at the default volume level. Regardless of the arming mode.

Full battery capacity

3,200 mAh

Capacity of each battery is 1,600 mAh.

Low battery voltage

2.1 V⎓

End-of-life battery voltage

1.9 V⎓

Device is switched off.

End-of-life battery capacity

366 mAh

Manufacturer

Huiderui

UL listed.

HomeSiren Jeweller

SmartBracket mounting panel

2 × CR123A battery (pre-installed)

Connector for an LED indicator

Installation kit

Quick start guide
