Superior KeyPad Plus G3 Jeweller

Superior Jeweller data transfer protocol

Proprietary wireless protocol for transmitting commands, alarms, and events. An upgraded version of the Jeweller radio protocol for Superior devices, ensuring compliance with Grade 3 (EN 50131).

Key features:

• Two-way communication.
• Advanced sabotage protection.
• Enhanced block encryption with a dynamic key.
• Instant notifications.
• Remote control and configuration in Ajax apps.

Frequency bands

865.0–868.0 MHz

868.0–868.6 MHz

868.7–869.2 MHz

869.4–869.65 MHz

Maximum effective radiated power (ERP)

up to 20 mW

Automatic power control to reduce power consumption and radio interference.

Radio signal modulation

GFSK

Radio communication range

up to 11,450 ft (TBC)

Between the device and a hub (or a range extender) in open space. The maximum range depends on the hub model.

Encrypted communication

All stored and transmitted data is protected with advanced encryption, ensuring both confidentiality and integrity.

Frequency hopping

To prevent radio interference and jamming.

Sensor type

capacitive

Authentication methods

• access codes
• Tag key fobs
• Pass cards

Access codes

• keypad code

1 per each Superior KeyPad Plus G3 Jeweller.

• user codes

1 per user. The total number depends on the hub model.

• unregistered user codes

1 per user not registered in an Ajax system. The total number depends on the hub model.

• duress codes

1 per each Superior KeyPad Plus G3 Jeweller and 1 per each user. The total number depends on the hub model.

Contactless access

DESFire® EV1, EV2, EV3

ISO 14443-А (13.56 MHz)

Arming without entering a code

When enabled, this feature allows users to arm the facility without entering a code or presenting an access device.

Group security management

Users can change the security mode of groups they have access to directly from the keypad.

Authorization confirmation with a passcode

This feature activates two-factor authentication. When enabled, users must first present an access device (Pass or Tag) and then enter a passcode to confirm authorization.

Function button

Operates in one of the following modes:

• panic

Sends an alarm to the central monitoring station and users. Also activates the sirens connected to the system.

• mute fire alarm

Mutes alarms triggered by interconnected fire detectors.

• none

The button is disabled.

Indication of malfunctions and security mode

When enabled, the keypad uses LED indicators to show the current security mode, as well as detector malfunctions or loss of communication with the hub.

ACE Type

type B

Unauthorized access auto-lock

The keypad locks if an incorrect code is entered or unverified access devices are used more than 3 times in a row within 1 minute. The lock duration can be adjusted by a PRO or user with admin rights in an Ajax app.

Tamper alarm

The system sends notifications about attempts to detach the keypad from the surface or remove it from the mounting panel.

Holding screw

Secures the device on SmartBracket.

Protection against spoofing

Ensures device authentication during communication with a hub.

Communication loss detection

after 36 seconds of no signal

Detection time depends on Jeweller or Jeweller/Fibra settings.

Battery

4 × AA

Pre-installed.

Type

type C

Calculated battery life

TBC

Operating voltage range

2.25−3.30 V⎓

Nominal operating voltage

3 V⎓

Quiescent current consumption at nominal voltage

130 μA

Maximum current consumption at nominal voltage

10.5 mA

Full battery capacity

6,000 mAh

Low battery voltage

2.5 V⎓

Low battery recovery voltage

2.7 V⎓

End-of-life battery voltage

2.25 V⎓

The device switches off.

End-of-life battery capacity

500 mAh

Manufacturer

Energizer

Superior KeyPad Plus G3 Jeweller

4 × AA battery (pre-installed)

SmartBracket mounting panel

Installation kit

Quick start guide
